Highlights
- Mounting width: 2 WM (35 mm)
- Circuit-breaker with two floating interlocked relay switching outputs for opening and closing e.g. shutters and awnings that have limit switches (mechanical or electronic) and 230 V AC motors
- As many floating buttons as are necessary can be connected to one button input
- Interference-proof thanks to bus cabling
- Easy programming at the device itself
Technical Specifications
Supply voltage
24 VDC
Current consumption
70 mA (max.)
Max. switching capacity
230 V/50 Hz/4 A motor load
Degree of protection
IP20
Ambient temperature
0 to 35 °C
Dimensions (W x H x D)
35 x 87 x 64 mm (2 WM width)
Weight
100 g
Communication
RS485 bus
Ordering Informations
Product Name
HMW-LC-Bl1-DR
Item Number
76802
EAN Code
4047976768035
Package
90
Dimesions incl. Packaging
122 x 112 x 48 mm
Weight incl. Packaging
176,2 g
