Highlights
- Convenient dimming and atmospheric lighting with the wireless dimming actuator for concealed installation
- Super-flat design
- Easy installation with fastening tabs
- Low standby power consumption
- Signal LED confirms that the radio signal has been received, for example
- Multiple remote controls can be connected
- Maximum ON time can be individually defined
Technical Specifications
Supply voltage
230 V/50 Hz
Current consumption
1.8 A (max.)
Power consumption in standby
1 W
Effective installed load
400 VA max.
Degree of protection
IP20
Device protection
Fuse protection for overloads and overtemperatures
Dimensions (W x H x D)
49 x 34 x 148 mm
Weight
94.2 g
Radio frequency
868.3 MHz
Typ. open area RF range
300 m
Ordering Informations
Product Name
HM-LC-Dim1T-CV
Item Number
85974
EAN Code
4047976859740
Package
72
Dimesions incl. Packaging
184 x 93 x 48 mm
Weight incl. Packaging
176,2 g
