Highlights
- Change in a switching state is detected, stored and transmitted to connected Homematic components in the form of a radio command
- Configuration via Homematic Central Control Unit CCU2
- Battery life of over three years (based on a usage rate of six times per day)
- The slimline design means it can be easily installed in a flush-mounting box
- Can be installed even behind push-buttons or switches
Technical Specifications
Supply voltage
1x Lithium coin cell CR2032
Battery life
3 years (typically), based on a usage rate of 6 times per day
Degree of protection
IP20
Ambient temperature
5 to 35 °C
Dimensions (ø x H)
50 x 10 mm
Weight
30 g (not incl. battery)
Radio frequency
868.3 MHz
Typ. open area RF range
200 m
Ordering Informations
Product Name
HM-SCI-3-FM
Item Number
92068
EAN Code
4047976920686
Package
144
Dimesions incl. Packaging
122 x 93 x 36 mm
Weight incl. Packaging
82,8 g
