Highlights
- Activation of a 12 V siren and a 12 V flashing light
- Preset statutory signal duration for flashing light and siren
- Jet-proof (IP65), suitable for outdoor application
- Internal tamper contact provides tamper protection
- Internal battery status monitoring, deep discharge protection and protection against polarity reversal
- All Homematic transmitters can be connected
- Back-up supply via lead gel battery
Technical Specifications
Supply voltage
230 V/50 Hz
Current consumption
30 mA (max.)
Switching outputs
2x 12 VDC, total load 1 A max.
Back-up supply
Lead gel battery, 12 V/1.2 Ah
Degree of protection
IP65
Operating temperature
-10 to +50 °C
Dimensions (W x H x D)
160 x 160 x 90 mm
Weight
692 g
Radio frequency
868.3 MHz
Typ. open area RF range
300 m
Ordering Informations
Product Name
HM-Sec-SFA-SM
Item Number
84392
EAN Code
4047976843923
Package
10
Dimesions incl. Packaging
184 x 281 x 97 mm
Weight incl. Packaging
1596,0 g
