Highlights
- Optical scattered-light smoke alarm with VdS certification and Q label
- Maintenance-free thanks to battery life of up to 10 years
- Wireless Smoke Alarm based on Homematic wireless protocol and offering AES-128 security
- Up to 40 Homematic Wireless Smoke Alarms can be connected
- Emergency lighting by integrated LED during alarm
- Metal mash around smoke chamber for protection against insects
- Easy installation with supplied screws and plugs
- Large and user-friendly push-button for functional tests and muting alarms
- Self-test and battery control function
Note: The device may only be operated in groups with smoke alarms of the same type
(HM-Sec-SD-2 , part-no. 131408) and not with other types of smoke alarms (e.g.
HM-Sec-SD, part-no. 76676 and 83813).
VdS G216001
eQ-3 AG
Maiburger Straße 29
26789 Leer
Technical Specifications
Supply voltage
Permanently installed 3 V lithium batteries
Battery life
10 years (typ.)
Degree of protection
IP20
Ambient temperature
5 to 30 °C
Typ. open area RF range
300 m
Radio frequency
868.3 MHz
Alarm type
Scattered-light wireless smoke alarm
Alarm output
Piezo signal device (>85 dB in 3 m distance), status LED, radio
Display
Duo status LED
Mark of conformity
CE, VdS, Q-label
Dimensions (ø x H)
110 x 45 mm
Weight
146 g (incl. batteries)
Ordering Informations
Product Name
HM-Sec-SD-2
Item Number
131408
EAN Code
4047976314089
Package
32
Dimesions incl. Packaging
184 x 140 x 73 mm
Weight incl. Packaging
325,0 g
