Highlights
- Connections for conventional push-buttons
- Operation on the device is possible using push-buttons
- Low current consumption
- Multiple remote controls can be connected
- Signal LED confirms that the radio signal has been received, for example
- Maximum ON time can be individually defined
Technical Specifications
Supply voltage
230 V/50 Hz
Typ. open area RF range
200 m
Radio frequency
868,3 MHz
Ambient temperature
5 °C to 35 °C
Power consumption in standby
0.5 W
Relay
NO contact (2x)
Switching capacity
5 A (ohmic load, sum of both channels)
Degree of protection
IP20
Dimensions (W x H x D)
53 x 53 x 30 mm
Weight
47,8 g
Ordering Informations
Product Name
HM-LC-Sw2-FM
Item Number
76794
EAN Code
4047976767946
Package
90
Dimesions incl. Packaging
122 x 112 x 48 mm
Weight incl. Packaging
120,3 g
