Highlights
- 4 independent switching channels
- 4 buttons for direct control on the device
- Direct teaching-in of e.g. wireless push-buttons or remote controls enables comfortable switching of connected loads
- Several remote controls can be connected to one switching channel (even without Homematic Central Control Unit CCU2)
- Relay contact: NO contact (4x) floating
- Low standby power consumption
- Channel LEDs for status display
- Power supply can be provided via external power supply unit (not included in the package contents)
- Maximum ON time can be configured (only in connection with the
- Homematic Central Control Unit CCU2)
Technical Specifications
Supply voltage
7-15 VDC
Current consumption
26 mA
Power consumption in standby
0.2 W
Max. switching capacity
1 A (ohmic load), 42 VDC, 30 VAC
Relay
4x NO contact
Degree of protection
IP20
Typ. open area RF range
300 m
Radio frequency
868.3 MHz
Dimensions (W x H x D)
89 x 99 x 26 mm
Weight
81 g
Ordering Informations
Product Name
HM-LC-Sw4-WM
Item Number
99082
EAN Code
4047976990825
Package
90
Dimesions incl. Packaging
122 x 112 x 48 mm
Weight incl. Packaging
152,4 g
