Highlights
- The slimline design means it can be easily installed in a flush-mounting box
- All Homematic actuators can be taught-in directly
- Standard switches for electrical installations can be connected (two-way or intermediate switches)
- Long battery lifetime is possible thanks to energy-saving circuitry
Technical Specifications
Supply voltage
1x Lithium coin cell CR2032
Battery life
3 years (typically), based on a usage rate of 6 times per day
Degree of protection
IP20
Ambient temperature
5 to 35 °C
Dimensions (ø x H)
50 x 10 mm
Weight
30 g (not incl. battery)
Radio frequency
868.3 MHz
Typ. open area RF range
100 m
Ordering Informations
Product Name
HM-SwI-3-FM
Item Number
76785
EAN Code
4047976767854
Package
144
Dimesions incl. Packaging
122 x 93 x 36 mm
Weight incl. Packaging
80.8 g
