Highlights
- Ideal for monitoring garage doors, hatches, roof windows, containers and many other applications
- Detects deviations from the original position of a hatch, a garage door or a roof window
- Option of customising trigger point/angle of inclination setting
- Customisation to local conditions prevents false tripping caused by the wind or cars driving by
- Once the angle of inclination is changed, a switching command is triggered
- Compact, weather-proof housing (IP65) is suitable for outdoor applications
- Can be positioned anywhere as it runs on batteries, no wiring work required
- Long battery lifetime
Technical Specifications
Supply voltage
1x lithium coin cell CR2032
Battery life
3 years (typ.)
Degree of protection
IP65
Dimensions (W x H x D)
50 x 50 x 35 mm
Weight
55.6 g
Radio frequency
868.3 MHz
Typ. open area RF range
200 m
Ordering Informations
Product Name
HM-Sec-TiS
Item Number
83146
EAN Code
4047976831463
Package
90
Dimesions incl. Packaging
122 x 112 x 48 mm
Weight incl. Packaging
126,6 g
