Highlights
- Comfortable, silent and secure opening and closing of windows at the touch of a button or using automatic time control
- Adjustable timer function enables automatic closing of windows within a period of 1 to 99 minutes
- Control keys on the device
- Battery-powered and mains operation possible
- Tilt position of the window can be configured
- Large status display
- Easy to fit on the right-hand or left-hand casement
- Colour-matched to standard window profiles
- Secure thanks to AES authentication
Technical Specifications
Supply voltage
10.8 VDC via battery pack (optionally available)
Typ. open area RF range
200 m
Radio frequency
868.3 MHz
Battery life
approx. 80 days (based on a usage range of 4 times/day without recharging)
Display
LC display 20 x 14 mm
Power consumption in standby
1,2 Watt / 6,5 Watt (during recharging)
Degree of protection
IP20
Dimension (W x H x D)
59 x 319 x 80 mm (incl. battery)
Weight
770 g (without battery pack)
1110 g (incl. battery pack)
Ordering Informations
Product Name
HM-Sec-Win
Item Number
83373
EAN Code
4047976833733
Package
10
Dimesions incl. Packaging
184 x 281 x 97 mm
Weight incl. Packaging
1.828,8 g
