Highlights
- Compact and inconspicuous design
- Spacers for adaptation to different types of casement supplied
- Easy installation thanks to battery operation
- Tamper contact detects manipulation or unauthorised removal
- Secure thanks to AES authentication
Technical Specifications
Voltage supply
2x 1.5 V LR44
Current consumption
35 mA max.
Battery life
2 years (typically), based on a usage rate of 4 times per day
Degree of protection
IP20
Ambient temperature
5 °C to 35 °C
Dimensions sensor (W x H x D)
17 x 77 x 16 mm
Dimensions magnet (W x H x D)
12 x 48 x 12 mm
Weight
32 g (incl. batteries)
Radio frequency
868.3 MHz
Typ. open area RF range
200 m
Ordering Informations
Product Name
HM-Sec-SC-2
Item Number
131775
EAN Code
4047976317752
Package
144
Dimesions incl. Packaging
122 x 93 x 36 mm
Weight incl. Packaging
97,9 g
