Highlights
- Automatic regulation of radiators in connection with the MAX! Cube LAN Gateway and/or the MAX! Wall Thermostat+
- Can be individually tailored to personal routines thanks to the freely programmable heating phases (13 switching times per day for temperature switch-over) via the MAX! software
- Easy installation without having to intervene in the heating system; no special tools required
- Ready to use straight away thanks to pre-set week programs
- Precise temperature adjustment (to the nearest 0.5°C)
- Automatic temperature reduction when windows are opened for ventilation and adjustment of the temperature when they are closed in connection with MAX! Window Sensors
- Frost protection function automatically opens valves if necessary
- Limescale protection automatically protects against calcification thanks to regular opening and closing of the valves
- Boost function for heating up the radiator immediately
- Tamper-proof thanks to child-proof lock/operating lock
Technical Specifications
Supply voltage
2x 1.5 V LR6/mignon/AA batteries
Current consumption
100 mA max.
Battery life
2 years (typ.)
Display
LCD
Threaded connection
M30 x 1.5 mm
Dimensions (W x H x D)
55 x 60 x 102 mm
Weight
160 g (not incl. batteries)
Radio frequency
868.3 MHz
Typ. open area RF range
> 100 m
Ordering Informations
Product Name
BC-RT-TRX-CyN
Item Number
142016A1
EAN Code
4047976420162
Package
75
Dimesions incl. Packaging
69 x 66 x 111 mm
Weight incl. Packaging
320,0 g
